IPC-2581 Import

Extension module for our PCB CAM Web App

Use this module at www.pcb-cam-online.com.

This extension module allows you to import data in IPC-2581 format. Visualize your design and easily interact with it using our PCB CAM Web App. Take advantage of the benefits of IPC-2581.

This extension module supports the formats IPC-2581 A and IPC-2581 B.

As a manufacturer independent format, IPC-2581 ensures a cross-company and cross-process CAD flow starting from PCB tools to manufacturing with only a single data format. IPC-2581 is therefore an open, neutral and global standard for highly efficient and comprehensive CAD data exchange. It is an essential goal of IPC-2581 to transfer as much undocumented knowledge as possible and to make changes transparent.

Please select how many months you want to use the extension module. One-time payment.

 Independent of the choice of extension module, the import of the formats Gerber274x X2/X3, Excellon and Sieb & Meyer is already included as free basic functionality!

9,90 € per month

Qty:

month(s)

Further information

Note:
To be able to use this extension module without restrictions, please allow popups for the PCB CAM Web App in your browser.

Details:
This standard has progressively established as an attractive alternative to traditional manufacturing output data, which usually consists of a collection of e.g. Gerber, drilling, parts list and text files.

A single IPC-2581 XML file can include:

Copper image information for etching PCB layers.
PCB layer stack information (including rigid and flexible sections).
Netlist for PCB and in-circuit tests.
Component bill of materials for purchasing and assembly (pick & place).
Notes and parameters for manufacturing and assembly.

You want to benefit from the many benefits of IPC-2581? With the PCB CAM Web App and the extension module "IPC-2581 Import", you can visualize your data within seconds!

Convince yourself! Just order the "IPC-2581 Import" for a period of one month or longer!

Customers who bought this item also bought

ODB++ Import

Extension module for our PCB CAM Web App

Use this module at www.pcb-cam-online.com.

Choosing this extension module, you will be able to also import ODB++ data. Visualize your design and easily interact with it with our PCB CAM Web App. Take advantage of the intelligent data format ODB++!

Data formats with various dialects, such as RS274X, may produce different results on different CAM systems. This can cause considerable damage. ODB++ significantly improves quality by avoiding data exchange errors. Thanks to the distinct definition, multiple interpretations become a thing of the past.

Formats up to ODB++ 8.1 Update 2 are supported.

Please select how many months you want to use the extension module. One-time payment.

9,90 € per month

EAGLE Import

Extension module for our PCB CAM Web App

Use this module at www.pcb-cam-online.com.

This extension module enables you to now also import data of the format EAGLE. Visualize your design and interact with it easily in our PCB CAM Web App. Benefit from the specific advantages of EAGLE.
PCB layouts created with EAGLE (Easy Applicable Graphical Layout) editor from Autodesk are saved as *.brd files. Highly functional designs can thereby be created quickly. With the expandable PCB CAM Web App, you can directly import these files and view them in detail without the need for any additional steps or effort.
So, if you opt for an uncomplicated visualization of your Eagle files, go for the "EAGLE Import" extension module!

Please select how many months you want to use the extension module. One-time payment.

9,90 € per month

Basic module

Free basic module for our PCB CAM Web App

Use this module at www.pcb-cam-online.com.

With this module, you are able to upload and visualize all your designs in the popular formats Gerber 274x X2/X3, Excellon and Sieb&Meyer - completely free of charge.

Enjoy the new and pleasant working experience of PCB CAM Web App thanks to its speed and performance!

0,00 €

GenCAD Import

Extension module for our PCB CAM Web App

Use this module at www.pcb-cam-online.com.

This extension module allows you to import data of the GenCAD format. Visualize your design and interact with it easily in our PCB CAM Web App. Benefit from the special advantages of GenCAD 1.4!

Besides ODB++ and IPC 2581, GenCAD is one of the most recognized data formats for electronic data exchange. Its main focus lies on the manufacturing and testing of PCBs.

Please select how many months you want to use the extension module. One-time payment.

9,90 € per month
