PCB-Investigator Basic (Dongle)

License type: DONGLE

BASIC version focuses on the essential functions to carry out a design review. But: You can expand it at any time and at your discretion through our unique Automation Interface. So, you are able to integrate your own plugins to further facilitate your work through automation. PCB-Investigator is thus characterized by the highest flexibility on market.

More information about this version: 🡒 Whitepaper

This product includes support and update service for one year.
*
  • Purchase this product including one year support and maintenance
  • Lease this product including support service for one year.
Call for pricing
Further information

➔ Want to get a quick overview?

➔ Looking for an easy-to-use software that accompanies the review process of your PCB design, but is not overloaded with unnecessary tools?

➔ Don’t want a software that is a rigid system, but a solution adaptable to your individual requirements?

Then, Edition BASIC is exactly the right choice for your particular needs. This version is mainly bought by project managers and procurement officers. They highly appreciate BASIC as a major help in their everyday work.

BASIC version focuses on the essential functions to carry out a design review. But: You can expand it at any time and at your discretion through our unique Automation Interface. So, you are able to integrate your own plugins to further facilitate your work through automation. PCB-Investigator is thus characterized by the highest flexibility on market.

Using BASIC, you will have the opportunity to get a quick overview and always stay in control without being flooded with data you do not require. At the same time, working with BASIC increases transparency in communication and therefore also efficiency of work processes in teams – a great simplification of everyday work.

The software’s ultra-easy operation makes it much more convenient for you to carry out the important review process or to order the required components – high-quality and functional PCBs in short development cycles are the result.

BASIC includes among others the following functions:

  • Automation Interface (.Net, C#, VB, .Net, C++)
  • 3D view
  • DXF export
  • Excel CSV export
  • Excellon 1/2 Import
  • Gerber274x Import / Export
  • ODB++ Import / Export
  • top bot view
  • Add Image (PBG, JPG, BMP)

------------------------------------------------------------------------------------------

Dongle:

With this license you will receive a USB dongle. If this dongle is connected to a PC, the software can be used there - no matter which PC it is.

Floating:

Here you have the possibility to manage all licenses centrally. You can choose between two variants: With the self-hosted version, you have to run a PC/server - on which all licenses are held - with a "floating server software" around the clock. Alternatively, you can hold your licenses centrally in our SOD via web service. In both cases, the following applies: Any number of PCs in your company can check out a license, but never more than total number of licenses at the same time. For example, if you have 10 licenses, a maximum of 10 users can use the software at the same time, but with every computer in the network.
