All given prices are net prices.

PCB-Investigator Ultimate (Dongle)

License type: DONGLE

The ULTIMATE version therefore combines all functionalities of the FABRICATION and ELECTRONIC DEVELOPER editions! On one hand, you can guarantee the functionality and safety of your PCB by working out all electronic details. On the other hand, you gain access to all necessary tools to prepare, manage and monitor production ensuring a reliable production result for your customers.

This product includes support and update service for one year.
*
  • Purchase this product including one year support and maintenance
  • Lease this product including support service for one year.
Call for pricing
Further information

➔ Looking for a software that enables a comprehensive review process?

➔ The software should enable you to work out both production-relevant and electronic details in the easiest possible way?

➔ You wish to increasingly automate processes and thus are you looking for a flexible software solution that can be adapted to your individual requirements?

Then the ULTIMATE edition is exactly the right choice for your special requirements. Particularly administrators as well as people involved in many areas of PCB development benefit from the advantages of ULTIMATE. Because with ULTIMATE you maintain a clear overview, both for production and electronic development.

The ULTIMATE version therefore combines all functionalities of the FABRICATION and ELECTRONIC DEVELOPER editions! On one hand, you can guarantee the functionality and safety of your PCB by working out all electronic details. On the other hand, you gain access to all necessary tools to prepare, manage and monitor production ensuring a reliable production result for your customers.

This quick eye for details enables a faster, more effective and therefore cheaper PCB development.

Our one-software solution puts an end to the software chaos that required numerous separate tools for review processes and product verification. ULTIMATE offers you the all-round carefree package with an enormous variety of functions and at the same time easy handling. In addition, you always keep the possibility to add further individual automations or extensions by using the special automation interface of PCB-Investigator - making ULTIMATE even better! There is a virtually infinite number of possibilities available to you, our support team will gladly assist you with any questions you may have.

PCB-Investigator ULTIMATE includes among others the following functions:

  • Net group manager
  • Net length & capacity calculator
  • Automation interface and script engine
  • Additional import/export formats (e.g. GenCad, IDF, IPC2581)
  • Bare Board Analysis (DRC)
  • Panel Builder including Nesting algorithm
  • Stencil Analysis
  • Creepage Analysis
  • Hazard Analysis
  • Connector Analysis
  • Design compare

------------------------------------------------------------------------------------------

Dongle:

With this license you will receive a USB dongle. If this dongle is connected to a PC, the software can be used there - no matter which PC it is.

Floating:

Here you have the possibility to manage all licenses centrally. You can choose between two variants: With the self-hosted version, you have to run a PC/server - on which all licenses are held - with a "floating server software" around the clock. Alternatively, you can hold your licenses centrally in our SOD via web service. In both cases, the following applies: Any number of PCs in your company can check out a license, but never more than total number of licenses at the same time. For example, if you have 10 licenses, a maximum of 10 users can use the software at the same time, but with every computer in the network.
