PCB-Investigator Production Control (Dongle)
License type: DONGLE
This edition includes the full functionality of FABRICATION, which was made specially to support production. Additionally, we offer you the possibility to directly control machines from the major manufacturers such as Viscom, Parmi, Excellon, Kurtz Ersa, Göpel or Posalux.
More information about this version: 🡒Whitepaper This product includes support and update service for one year.
Purchase this product including one year support and maintenance
Lease this product including support service for one year.
➔ Looking for a tool that supports you in guiding and monitoring the production for bare boards and assembly?
➔ Want to directly access machines without the need to familiarize yourself with another complex software?
➔ Want to reduce production costs by using only one single software and at the same time advance automation?
Then, edition PRODUCTION CONTROL is exactly the right choice for your individual requirements. This newly released version offers all the tools you need for working in the production or assembly of printed circuit boards.
It includes the full functionality of FABRICATION, which was made specially to support production. Additionally, we offer you the possibility to directly control machines from the major manufacturers such as Viscom, Parmi, Excellon, Kurtz Ersa, Göpel or Posalux.
Stop the software chaos, PRODUCTION CONTROL is all you need for your daily work in production!
So, if you choose PRODUCTION CONTROL, we will equip you with a specialized software package to be ideally prepared for the manufacturing of your PCB designs. Find possible sources of malfunction early to keep error rates as low as possible – guarantee risk management of your boards!
PRODUCTION CONTROL version contains among others the following functions:
- Machine Export
- Panel Builder including Nesting algorithm
- Stencil Analysis
- Bare Board Analysis (DRC)
- Tombstone and Component Analysis
- Test point report o Component editing functions
- Automation interface and script engine
- Additional import/export formats (e.g. GenCad, IDF, IPC2581)
- Design compare
With this license you will receive a USB dongle. If this dongle is connected to a PC, the software can be used there - no matter which PC it is.
Here you have the possibility to manage all licenses centrally. You can choose between two variants: With the self-hosted version, you have to run a PC/server - on which all licenses are held - with a "floating server software" around the clock. Alternatively, you can hold your licenses centrally in our SOD via web service. In both cases, the following applies: Any number of PCs in your company can check out a license, but never more than total number of licenses at the same time. For example, if you have 10 licenses, a maximum of 10 users can use the software at the same time, but with every computer in the network.
