All given prices are net prices.

PCB-Investigator Fabrication (Floating)

License type: FLOATING

FABRICATION includes all tools you need to prepare, manage and monitor production, so that you can provide a more reliable and consistent production result while shortening time to market and lowering costs for you and your customers. Find possible error sources before you start production and avoid unnecessary additional costs - using FABRICATION you can accomplish this task easier and faster than ever before!

More information about this version: 🡒Whitepaper

This product includes support and update service for one year.
Single Site License: The license is tied to a single location of the company. If you are interested in a "Continental" or "Global" license, please contact us.
*
  • Purchase this product including one year support and maintenance
  • Lease this product including support service for one year.
Call for pricing
Further information

➔Looking for a tool that supports you in guiding and monitoring the production for bare boards and assembly?

➔Want to play it safe and guarantee 100% producibility at all times?

➔Striving to automate processes in order to effectively shorten the time to market?

Then, edition FABRICATION is exactly the right choice for your specific needs. Particularly production planners, EMS provider and PCB manufacturer appreciate FABRICATION for its reliability, the possibilities of automating work processes and its specialized applicability in manufacturing issues.

FABRICATION includes all tools you need to prepare, manage and monitor production, so that you can provide a more reliable and consistent production result while shortening time to market and lowering costs for you and your customers. Find possible error sources before you start production and avoid unnecessary additional costs - using FABRICATION you can accomplish this task easier and faster than ever before!

So, if you choose FABRICATION, we will equip you with the perfect tool to be ideally prepared for the production of your PCB designs – offering you a variety of plug-ins that are tailored to your needs in manufacturing. Do not lose sight of the most important aspects and manufacture your products according to the highest quality standards.

Our FABRICATION tool supports you in your everyday tasks and relieves you by automating processes.

FABRICATION contains among others the following functions:

  • Panel Builder including Nesting algorithm
  • Stencil Analysis
  • Bare Board Analysis (DRC)
  • Tombstone and Component Analysis
  • Test point report
  • Component editing functions o Automation interface and script engine
  • Additional import/export formats (e.g. GenCad, IDF, IPC2581)
  • Design compare

------------------------------------------------------------------------------------------

* Dongle:

With this license you will receive a USB dongle. If this dongle is connected to a PC, the software can be used there - no matter which PC it is.

* Floating:

Here you have the possibility to manage all licenses centrally. You can choose between two variants: With the self-hosted version, you have to run a PC/server - on which all licenses are held - with a "floating server software" around the clock. Alternatively, you can hold your licenses centrally in our SOD via web service. In both cases, the following applies: Any number of PCs in your company can check out a license, but never more than total number of licenses at the same time. For example, if you have 10 licenses, a maximum of 10 users can use the software at the same time, but with every computer in the network.
